PHASEBEAM
PHASEBEAM is a low-cost solution platform, which is ideal for low-power FR1 5G applications spanning 3.3 – 4.1 GHz.
PHASEBEAM is based on P1D1A1, which is a multi-channel transceiver designed for use as a 2x2 MIMO transceiver. P1D1A1 can be used in both handsets and FWA devices. In the case of a handset, P1D1A1 is used in conjunction with H11D1A1, which is a 2-channel single-pole double-throw RF switch that interfaces the P1D1A1 to 2Tx and 2Rx MIMO antennas. For an FWA device, P1D1A1 is used with 4x FR1 antennas, supporting 2Tx paths and 2Rx paths.
- FR1
• 2x2 MIMO Solution
• Peak saturated power 10dBm
• Low-noise figure
• High Tx/Rx gain - Beamforming with transceiver and front-end integration
• 2Tx + 2Rx beamforming transceiver
• 6-bit 360° phase step control
• 5-bit gain step control
